4 Axle Fuel Tanker Trailer

About 4 Axle Fuel Tanker Trailer Tanker

The fuel tanker trailer is designed to be compatible with different types of media, including oil, fuel, alcohol, cooking oil, and other non-corrosive liquids. However, it is essential to ensure that the trailer is suitable for the specific media being transported and complies with relevant regulations. Fuel tanker trailers are equipped with various safety features to ensure secure transportation.

4 Axle Fuel Tanker Trailer Tanker Specification

Axle: 4x13000kg, 4 axle, FUWA brand

Tire: 315/80R22.5, 16+1 pcs, TRIANGLE brand

Kingpin: 3.5 inch, JOST brand

Brake System: WABCO brand

Support Leg: 28 tons, JOST brand

Tanker Body: 54000 liters, 6 compartment

Dimension: 13050x2520x3650mm

The 4 axle fuel tanker trailer specification only for your reference, we can manufacture other model fuel tanker trailer basic your request.

4 Axle Fuel Tanker Trailer Tanker Body Detail

The tanker body is designed to store and transport liquids safely and efficiently. It is typically constructed using high-quality materials, such as aluminum or steel, to ensure durability and resistance to corrosion. The loading capacity of the fuel tanker trailer can be customized according to specific needs. The standard capacity of 54,000 liters provides a significant volume for transporting various types of media.

4 Axle Fuel Tanker Trailer Tanker Welding Tech

Fuel tanker trailer adopt the automatic submerged welding tech. The first step need use the laser cutting machinery to cut the steel Improved cutting accuracy. Then, using automated CNC plate rolling machine control, the cylinder is formed at one time, the inner part of the plate will not be damaged, and the moulding quality is stable and reliable. Finally, the automatic welding process is used to weld one side and form both sides, which gives the tank better strength.
