4 Axles Container Trailer

4 Axles Container Trailer Features

-. 16 tires can loading more cargoes, radial and tubeless model.

-. Main and side beam adopt the manganese plate, 350Mpa yield strength.

-. JOST brand 80 tons heavy duty support leg for drop and pull transportation.

-. 16 tons heavy duty loading axle, for other cargoes haulage, such as substation.

4 Axles Container Trailer Specification

Product Name: 4 Axles Container Trailer

Application: Container transport

Axle: 4 axle, 4x16 tons, FUWA brand

Tire: 315/80R22.5, 16 pcs, TRIANGLE brand

Material: Manganese plate

Kingpin: 3.5 inch, JOST brand

Brake System: WABCO brand

Container Lock: 12 pcs

Support Leg: 28 tons, FUWA brand

Dimension: 12500x2500x1650mm

The 4 axles container trailer specification only for your reference, we can manufacture other model container trailer basic your request.

4 Axles Container Trailer Suspension

The 4 axles flatbed trailer suspension adopt two model, air and mechanical suspension. First axle is air suspension, can lifting when empty loading. And rear 3 axles is mechanical suspension for standard container transport. The leaf spring of 4 axles flatbed trailer adopt the heavy duty model 90x16mmx10pcs, TAIYUE brand.
