Bulk cement trailer can loading 40m3 all kind of dust material, the integrated tank body has the characteristics of high overall strength, good rigidity, good pressure bearing, and good performance. The fluidized bed in the tank is scientifically designed and reasonably arranged, which can effectively shorten the discharge time to 1.4T/min and improve the volume utilization rate of the tank.
3 Axle 40m3 Bulk Cement Trailer Advantage
1. Adopt international standard electrical system, long service life and easy maintenance.
2. The bulk cement semi trailer adopts a dual-line pneumatic braking system.
3. Use FUWA and JOST brand support leg, heavy duty model.
4. WEICHAI 4 cylinder engine supply extra power to loading and unloading all kind of dust material.
3 Axle 40m3 Bulk Cement Trailer Specification
Dimension: 11500x2560x3640mm
Axle: 3x16 tons, ZY brand
Tire: 315/80R22.5, 12 pcs, LINGLONG
Main Beam: lower 14mm, middle 10mm
Support Leg: JOST brand, 28 tons
Tractor Pin: JOST brand, 90#
Suspension: 8mm thickness, heavy duty loading
Leaf Spring: 90x16mmx10pcs
Wheel Rim: 18mm
Tanker Body: 40m3
Brake Valve: WABCO brand
The 3 axle 40m3 bulk cement trailer specification only for your reference, we can manufacture other bulk cement trailer basic your request.
3 Axle 40m3 Bulk Cement Trailer Working Principle
The working principle is that the air compressor sends the compressed air into the air chamber at the lower part of the sealed tank through the pipeline, so that the powder and particles on the liquefied bed of the air chamber are suspended into a fluid state. When the pressure in the tank reaches the rated value, the discharge valve is opened, the fluidized material flows through the pipeline for conveying and unloading.
