All TRUCKMAN Trailer Adopts Famous Brand,Such as:
Axle:
Famous Brand Axle Support
Trailer Durable and High Truck Attendance Rate
Chassis:
China Best Q345B-T700 support Stronger Trailer Skeleton
Tire:
Good Quality Tire support Trailer Running Safety&Smoothly
King Pin:
JOST Detachable Type support Durable and Fast&Easy Replace
Emergency Valve:
Fast Response,Low Failure support Safetly&Protect Tire Longer Time Use
|
Dimension(mm)
|
13000x2600x3420mm
|
|
Loading capacity(ton)
|
≤60T
|
|
Axles
|
3 axles, 13T/16T ,FUWA/ BPW/ Huajin/ZY Brand
|
|
Tire
|
12 units, 12.00R20 or 12.00R22.5 or 315/80R22.5
|
|
Rim
|
9.00-22.5 or 9.75-22.5
|
|
Suspension
|
Mechanical, Bogie, Airbag suspension(China brand or BPW brand)
|
|
Spring Leaf
|
90(W)mmx13(Thickness)mmx10 layers or 100mmx12mmx12 (specially intended for overseas markets)
|
|
King Pin
|
JOST brand 2.0 or 3.5 inch (bolted or welded)
|
|
Landing Gear
|
JOST brand D200T or Chinese brand 28tons(double-speed)
|
|
Main Beam
|
Height: 500mm, Upper plate:14mm, Middle plate:10mm, Bottom plate:16mm, Material:Q345B steel
|
|
Bottom Side Beam
|
16mm or 18mm steel channel (material: Q235 steel)
|
|
Bottom Platform
|
3mm-thick checkered plate
|
|
Trailer Sides
|
1800mm
|
|
Brake Chamber
|
WABCO RE 6 relay valve; T30/30+T30 spring brake chamber(TKL brand), 45L air tank
|
|
Twist Locks
|
4,8,12 sets (lifting or screw type)
|
|
Valve
|
WABCO valve (specially intended for oversea market)
|
|
ABS
|
Optional
|
|
Light
|
LED light (specially intended for oversea market)
|
|
Voltage
|
24V
|
|
Socket(Receptacle)
|
7-pin Socket (for 7 wire harness)
|
|
Tool Box
|
1m x 0.5m x 0.5m (The tool box contains 1 tire spanner, 1 gudgeon sleeve and 1 cranking bar. Its size can be tailored to suit your
needs)
|
|
Painting
|
Sandblasted, anti-rust chassis surface is available with 1 layer of anticorrosive primer and 2 layers of top coats
|
What are our advantages compared with other trailer manufacturers.
- Competitive Price -- our price is more competitive.
- Quick Response-- Our team is consisted of a group of diligent and enterprising people, working 24/7 to respond client inquiries and questions all the time. Most problems can be solved within 12 hours.
- Fast delivery -- we can have a 15-20 days delivery of regular trailers for our clients.
