Tactor tipper trailer is the front end of the trailer connected to the rear end of the tractor. Part of the total weight of the trailer is borne by the tractor. It doesn’t have itself power, it is carried together with the truck head, and the end dump trailer for sale is driven by the tractor.
We are the top one and professional semi-trailer supplier.
We can give you better product and favorable price.
TRUCKMAN AUTO has successfully entered into over 45 countries around the world.
Hydraulic tractor tipper trailer for sale can be customized from 15 tons to 80 tons semi tipper trailers for sale, 80 tons to 120 tons tipper tractor trailer, 120 tons-180 tons tipper semi trailer of different tonnage according to the different cargoes. The common volumes are 30 cubic meters semi tipper trailer, 32 cubic meters semi tipper for sale, 35 cubic meters, 45 cubic meters, 50 cubic meters, 60 cubic meters, 80 cubic meters and so on.
| Dimension: | 9500*2550*3500mm ( inside dimension ) |
| Tare Weight (semi trailer): | About 15600kg |
| Total volume(m³): | 30m³ or less than 100tons |
| Sidewall thickness: | 4 - 6mm |
| Endplate: | 8mm |
| Axle: | 13T/16T, FUWA / BPW / CIMC Brand |
| Rim: | 8.0-20 or 9.00-20 |
| Tire: | 8.25R20/10.00R20/11.00R20/12R22.5 |
| Suspension: | Mechanical suspension |
| Spring leaf: | 90(W)mmx13(Thickness)mmx10 layers |
| Kingpin: | JOST brand 2.0 or 3.5inch(bolted or welded type) |
| Landing gear: | JOST brand |
| Lifting System: | Full set of HYVA lifting cylinder |
| Main beam: Height: | 480mm-500mm, Upper plate: 16mm-25mm, |
| ABS: | Optional |
| Light: | LED light (especially intended for overseas markets) |
| Toolbox: | 1 set |
TIPPER SEMI TRAILER adopt advanced design concept.To make sure the servise life of the semi trailers, all the apare parts we adopt are World Famous brand.
For the tipper trailer box, we adopt high strength steel to make it durable when load the sand or small stones or rocks, especially under the off road condition.
For our tipper trailers, we can design the U type / Square type / container flatbed dumper, the capacity range is from 30 ton to 100 ton.
Submerged arc welding throughout beams, and other cross-section main stringers structure for optimum carrying effect.
Well-known brand axles, suspension systems, high performance, and reliable to use, to ensure the good performance of the vehicle.
TRUCKMAN dump tipper trailer are equipped with cylinder, which is more reliable and more safety
Full braking and electrical systems at home and abroad in accordance with ISO standard, optional ABS system, braking, lighting is absolutely safe and reliable.
We suppply tipper semi trailers with multiple customization options.
