The U shape tipper trailer has a maximum load capacity of 50 tons, allowing for the transportation of large volumes of materials such as sand, gravel, rocks, or construction debris.
60 Tons U Shape Tipper Trailer Hydraulic System
The U shape tipper trailer is equipped with a hydraulic system that powers the lifting and tipping mechanism. This system allows for easy and controlled lifting of the trailer bed to unload the materials. Brand of hydraulic system is optional the HYVA brand.
60 Tons U Shape Tipper Trailer Specification
Product Name: 50 Tons U Shape Tipper Trailer
Application: Coal and sand transport
Axle: 3 axle, 3x16 tons, FUWA brand
Tire: 315/80R22.5, 12 pcs, TRIANGLE brand
Material: Manganese steel
Kingpin: 3.5 inch, JOST brand
Brake System: WABCO brand
Cargo Body: 9500x2300x1500mm
Support Leg: 28 tons, YAHUA brand
Dimension: 10500x2500x3650mm
The 60 tons U shape tipper trailer specification only for your reference, we can manufacture other model U shape tipper trailer basic your request.
60 Tons U Shape Tipper Trailer Cargo Body
The tipper trailer features a U shape design, which allows for efficient loading and unloading of materials. The U shape design helps in preventing material spillage during transportation and ensures easy and complete unloading at the destination. And material of U shape cargo body adopt the manganese plate, HARDOX material, for difference cargoes haulage.
