Anti-fracture
National patented T-shaped beam, bearing capacity and torsion resistance are 3-5times that of traditional L-shaped longitudinal beam.
Anti-damage
ASME standard carbon steel tank body, three prismatic reinforcement ring,stress absorption and impact resistance.
Anti-vibration
Customized reduced-fit anti-seismic suspension, permanent hack bolt +shock-absorbing pad, the vehicle travels more stably.
Robot welding+patented Tooling fixture, the quality and strength of the weld are higher than that of the cylinder plate.
Anti-rollover
The center of gravity of the body and chassis is 5-10cm lower than that of peer manufacturers, the tank is lighter, and the safety and anti-rollover ability is stronger.
|
Dimension(L*W*H:mm)
|
12000×2500×3820(mm)
|
|
Body dimension(L*W*H:mm)
|
11550×2480×1950/2180
|
|
King pin setting(mm)
|
50# or 90#
|
|
Axle space(mm)
|
6130+1310+1310(mm)
|
|
Tare weight(kg)
|
8000(Kg)
|
|
Loading capacity
|
32000(Kg)
|
|
Landing gear
|
JOST E100 Two speed manual operation type with sand shoe
|
|
Kingpin
|
BAOHUA or JOST
|
|
Brake system
|
Wabco
|
|
ABS
|
4s/2M
|
|
Brake chamber
|
Type 30/30 spring brake system on all axles
|
|
Insulation layer
|
75mm glass fiber cotton
|
|
Suspension
|
Mechanical suspension leaf spring or air suspension
|
|
Axle
|
FUWA axle, 13 ton capacity/set, 4sets
|
|
Tire
|
12R22.5 16PR China famous brand
|
|
Bottom valves
|
one pcs of aluminum alloy material
|
|
Wheel Rim
|
9.0-22.5 16 pcs
|
|
Compartment
|
6
|
|
Tank material
|
Carbon steel
|
|
Bulkhead and Bafflr
|
Thickness is 6mm
|
|
Tank Shell
|
Thickness is 5mm
|
|
Shape of tank
|
circular shape
|
|
Manhole
|
2 pcs of aluminum alloy material
|
1.12months for main parts (engine, axle, body and beam, etc). 2. Technical Support by phone Whatsapp or email around the clock. 3. Lifelong Parts Supports. 4. Engineer available service oversea.
Fuel tanker trailer usually ship by bulk carriers or ro-ro ships. We spray wax on the tank. Cover it with a waterproof rain cloth. Some countries can also ship by container or frame cabinet.
