Full-trailer flatbed trailers are also called "full trailers, flatbed trailers, flatbed trailers, and trailers". They generally use pneumatic solid tires with low board height and large loading capacity.
20 Feet Container Full Trailer Truck Specifications:
Frame: Top flange plate: 16mm, Bottom flange plate: 16mm,
middle: 10mm. Side main beam: 6mm, cross
beam: 6mm, reinforced triangle beam:6mm,
Support beam: 4mm
Flatbed Size:7000*2500*1550mm
Flatbed Thickness: Floor 4mm Diamond checked, Side 3mm Horizontal Corrugations
Connector: Euro Italy Type Hooks and Bar
Axle: 3x13Ton FUWA axles.
Twist Locks: 6 sets
There are many types of full trailers, and the basic frame, body, and running system are basically the same as those of trucks. Railcars are generally made of thin steel plates. The rails of the carriages are stamped with longitudinal concave ribs, and transversely welded with ribs to increase the rigidity of the carriages and reduce the quality of the carriages; the floor of the carriages are generally made of wood and covered with thin steel plates. , Or use iron-wood mixed structure floor; the frame is usually made of 16Mn steel plate, pressed into profiles, welded or welded. The longitudinal and transverse beams of the frame mostly adopt a groove-shaped interface structure, and the two longitudinal beams are arranged at the front and rear with equal width, so that the frame has better bending resistance.
